Oyster 2 GPS Tracking Device

Oyster 2 is an ultra-rugged, long-life battery-powered GPS tracking device with up to 7 years battery life for small to medium size asset tracking and more.
This solution is ideal for industrial container tracking, trailer tracking and more! Get in touch with our friendly team to find the right monitoring device for your assets.

Main Features

  • High-precision GPS/GLONASS tracking device
  • Cellular 4G connectivity
  • Weatherproof and ultra-rugged IP67 Nylon Glass Housing with compact and ergonomic design
  • Powered by 3 x AA Batteries with up to 7 years battery life
  • The GPS tracking device is compatible with LTC Batteries for tracking in extreme temperatures
  • Accelerometer for Smart Movement Based Tracking
  • Configuration and management over-the-air (OTA)
  • Geo-Fences
  • Built-in Battery Meter for remote Battery Life Monitoring and Remaining Life Predictions
  • High-G Event Detection

Technical Details

Connectivity

GPS: uBlox EVA-M8, Concurrent GPS / GLONASS technologies
GPS signals are boosted by a unique low-noise amplifier (LNA) allowing operation where other units fail
4G: uBlox SARA-R410M Modem
Supported LTE Bands: 1*, 2, 3, 4, 5, 8, 12, 13, 18, 19, 20, 26*, 28 (*roaming bands)
SIM Size: Micro 3FF SIM

Dimensions (in mm): L 108 x W 86 x H 31
Weight: 190gr (batteries included)
Enclosure Rating: IP67
Recommended Operating Temperature: -20° to 85° C (with LTC batteries only)
Material: Ultra-Rugged Nylon Glass
Color: Black
Different Mounting Options Available: screws, magnets, cable-tie, rivets, VHB high strength adhesive

Battery Life: Up to 7 years (at 1 GPS location per day)
Up to 1 years (at 1 GPS location per hour)

Recommended Battery Type: AA type

  • Lithium Iron Disulphide (LiFeSO2) or
  • Lithium Thionyl Chloride (LTC) for an Extended operating temperature range and an extremely low self-discharge rate

Do not use Alkaline batteries

Quantity Needed per device: 3
Battery Replaceable: Yes
Battery Voltage: 1.5V per cell

Over-The-Air (OTA) Management: Configuration and firmware updates
Adaptive Tracking: Intelligently manage the frequency of GPS updates when it’s moving or stationary
Auto-APN: Select the correct APN details from a list that is pre-loaded in the device’s firmware
Battery Life Monitoring: Yes
Geo-Fences: Create custom areas and alerts if an asset enters or leaves specific locations. Monitor activity within the Geo-Fences
Impact Detection: Yes

3-axis Accelerometer: Yes

OEM Server: Manage, monitor, configure, debug, update, and restart devices remotely from the cloud-based device management system Telematics.guru: Customer-friendly platform to visualise and manage assets Third Party Integration: Webhook, TCP or HTTPS, Direct and Data Splitting Integration Options

Declaration of Conformity: RCM, CE, FCC
*Please contact us for a full list of compliance specifications and documentation for your region
